Glass or plastic bottles washing for pharmaceutical, Chemical, Beverage, food industry. Washing bottles of various sizes and large production capacity.

The Automatic Linear Tunnel Type Bottle Washing Machine consists of the main structure, bottle
holding pocket, in-feed tray, out-feed wiremesh conveyor, washing nozzle, PLC& HMI, electrical panel, motor, pumps with tank & AC drives.

Bottles pushed from Infeed tray and then move on wiremesh conveyor belt, which align the Bottle in correct position, to enter into the carrier pocket with help of oscillating guide rails. Oscillating arm deliver the Bottle inside pocket in mouth down position over spraying nozzles. MultiJet sprayers fixed at the top cause the total External and Internal surface to be Washed. To avoid any possible cross contamination between two different waters. Each washing station is provided with an independent Circuit. Carrier pocket is moving with indexing motion. When the baskets have completed their motion, the needles are lifted. They penetrate the Bottles, Spraying Jets of water or compressed air then Return Down. The baskets movement then advances by one Station. Each station of Bottles passes through the washing cycles selected. The duly washed Bottles then delivered to the Out-feed tray with neck opening upward and then automatically re ordered to a next Operation.
