360 Degree Wrap-Around Labeler for Round Bottles

About our products

360 Degree Wrap-Around Labeler for Round Bottles

Vials will be coming on moving conveyor of High-Speed Round Vial Sticker Labeling Machine. Once Vials are coming on conveyor, vials move to separator where Vial will be separated and vials move toward label wrapper one by one. Before coming to wrapper, product sensor sense vial, label sensor & dispensing motor give signal to each-other and label will be released. Released label will be wrapped around vial when vial pass through label wrapper and pressing pad.

Need Help?

Don't hesitate to contact us for more help

Shiv Shakti Machtech in Offering Complete Liquid Processing & Liquid Packaging Solutions to Segments Like Beverages, Chemicals, Cosmetics, Dairy, Detergents, Distilleries, Edible Oil, Fertilizers, Food, Nutraceuticals, Paints, Pharmaceutical, Lubricants Oil, Pesticides, Pigments, Plastics, and Other Liquid-based Manufacturing Industries.

Overview

In terms of operation, the 360-degree wrap-around labeler uses a sophisticated roller system that holds the round bottles securely as they rotate during the label application process. The rollers ensure the bottles remain stable, allowing for precise and wrinkle-free labeling. The machine is equipped with a servo motor and an intuitive control panel, enabling operators to adjust label placement, speed, and tension for different bottle sizes and types. This flexibility allows for quick changeovers between product runs, minimizing downtime and maximizing production efficiency. Additionally, the machine can handle a wide range of container diameters, making it adaptable to different labeling requirements. Built with high-quality materials, such as stainless steel, the machine is durable, easy to maintain, and compliant with industry standards, ensuring consistent and reliable performance in high-demand manufacturing environments.

Technical Specification :
BrandSSM
Model NumberSL-3 Roller
Number of Head1
Speed*Up to 40 bottle per minute (depends on label length, bottle material and diameter of bottle)
Suitable for ProductsGlass, plastic, PP, Pet, HDPE, LDPE, aluminum can, metal tin
Shape of ContainerCylindrical Container
Direction of MovementLeft of Right
Label roll specificationGap between two labels: maximum 3 mm
Core diameter: 75mm
External Diameter of roll: maximum 300mm
TypeFull Wrap Around / Positioning Label
Label Dispenser MotorServo Motor
Label accuracy+/- 0.5mm to 1mm
Container sizes Diameter: 20mm to 100mm
Height: 50mm to 250mm
(With help of change parts)
Label sizesHeight: 30mm to 145mm**
Length: 20mm to 280mm
(With help of change parts)
Height of Conveyor850mm (+50mm Adjustable)
Electrical Supply220 Volts, 1 Phase, 50 Hz.

Applications

this industry uses Our products

Pharmaceutical

Chemical

Beverage

Food industry
